Marketed Commodore monitors (including Escom Amiga Monitors): by model number
Excluding the Escom "Commodore KTC" (for PC) series

If you own Commodore monitors and want to improve this site, please take a few good quality pics of your monitor(s)
and send them to me. I am especially interested to see photos of front, back and inside of each monitor. Thanks!

Site by:
Varga Gábor (alias Gona) & Guru (co-author)

name	Commodore 1070		Amiga 1080		Commodore Amiga 1081 dark grey color picture tube; mono		Commodore Amiga 1081 dark grey color picture tube; stereo		Commodore Amiga 1081 light grey color picture tube; mono		Commodore 1083S-D1 (with "1084S" white badge)		Commodore 1083S-P1		Commodore 1084		Commodore 1084-D		Commodore 1084-P		Commodore 1084S-D		Commodore 1084S-D1 with gray badge		Commodore 1084S-D1 with white badge		Commodore 1084S-D2		Commodore 1084S-D2 black		Commodore 1084S-P		Commodore 1084S-P1		Commodore 1084S-P1 black		Commodore 1084S-P2		Commodore 1084ST		1084ST (post-Commodore but before Escom)		Commodore 1085S-D2 with gray badge		Commodore 1085S-D2 with white badge		Commodore 1085S-D3		Commodore 1201 beige		Commodore 1201 black		Commodore 1402		Commodore 1403		Commodore 1404		Commodore 1405		Commodore 1407		Commodore 1428		Commodore 1428 (Cornet-14")		Commodore 1428X		Commodore 1432D		Commodore 1432V		Commodore 1701		Commodore 1702		Commodore 1703		Commodore 1801		Commodore 1802 black/charcoal gray		Commodore 1802 dark brown		Commodore 1802 beige		Commodore 1802 (tall)		Commodore 1802D with gray badge		Commodore 1802D with white badge		Commodore 1803		Commodore 1900 M see: Commodore DM602	Commodore 1901 (later sold as Commodore 75BM13) monochrome		Commodore 1901 video monitor		Commodore 1902		Commodore 1902A		Commodore 1930		Commodore 1930-II		Commodore 1930-III		Commodore 1934		Commodore 1935		Commodore 1935LR		Commodore 1936		Commodore 1936LR		Commodore 1936A		Commodore 1936ALR		Commodore 1940		Commodore 1942		Commodore 1944		Commodore 1944S		Commodore 1950		Commodore 1960		Commodore 2002		Amiga 2024 see: Commodore A2024	Commodore 2080		75BM13 see: Commodore 1901 monochrome	Commodore 76BM13		monitor of the Commodore 900 prorotype machine see the 3rd to last column	Commodore 99STRIM		Commodore A2024		"Amiga HR" see the last column	Commodore BM13 see: 76BM13	Commodore CM-141		Commodore DM-14		Commodore DM602		Commodore M1 see: Commodore 76BM13	Commodore MM-14		Commodore RANGER 15	Commodore RANGER 21	Commodore SX-64 (built-in monitor)	Escom/Amiga Technologies M1438S		Escom/Amiga Technologies M1538S		Escom/Amiga Technologies M1764		Commodore "HR monitor" (HR=High Resolution) (no model name or number) [prototype]		Commodore 1902 [pre-production version]		"Amiga HR" (HR=High Resolution) [pre-production model]
picture	These images copyright by M.A.Grundke Source page: http://www.sothius.com (dead link)		Picture source: eBay.com		For these pictures special thanks to: Guru		For these pictures special thanks to: Luca ＠ www.nerdone.it		These images copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		This image taken by Zone		Picture source: eBay.fr		220-240V (PAL) version Picture source: eBay 100-120V (NTSC) version Picture source: Electric Thrift		These images copyright by Rabayjr.com (dead link) archived page: http://www.archive.org		Picture source: eBay.co.uk		Picture source: http://eab.abime.net		Picture source: eBay Picture source: bilgisararlarim.com		Picture source: eBay.de				Picture source: Big Book of Amiga Hardware		Picture source: eBay.de This image copyright by http://www.richardlagendijk.nl		These images by Guru		Picture source: eBay.de		Picture source: eBay.de		Picture source: Big Book of Amiga Hardware Picture source http://www.retrocomputer.tux.hu		These images from Picasa Web Albums by Marek (Dead Link)		These image copyright by http://www.richardlagendijk.nl		Picture source: allegro.pl		Picture source: eBay.de		Picture source: eBay.com.au		Picture source: eBay.com.au		These images copyright by Richard Lagendijk		These images copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		These images copyright by Richard Lagendijk		These image copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		These images copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		For these pictures special thanks to: Ernie Chorny		For these pictures special thanks to: Ernie Chorny		(front enclosure only) For this picture special thanks to: Ernie Chorny		For these pictures special thanks to: Ernie Chorny		For these pictures special thanks to: Ernie Chorny		Picture source: eBay.com		Picture source: eBay		Picture source: eBay Better picture wanted		This image copyright by www.classiccomputer.de Picture source: eBay		Picture source: eBay.com		For these pictures special thanks to: Mike Holmes		Picture source: eBay.com		This image copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl This photo from www.pcbonto.hu		This image copyright by atariport.com		Picture source: eBay.de		Picture source: eBay.fr			For these pictures special thanks to: Steve J. Gray		This image copyright by Arto Siili Source page: http://www.uta.fi/~as69841/cbm (dead link)		These images copyright by Robert Hurst		Picture source: eBay.com		These images copyright by Richard Lagendijk		These images copyright by Richard Lagendijk		These images copyright by Mingo's Commodorepage		These images copyright by Richard Lagendijk		These images copyright by Richard Lagendijk				These images copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		Picture source: vatera.hu		For these images special thanks to: Dorian Benedetti		These images copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		Picture source: www.tradera.com (Sweden)		These images copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		For this pictures special thanks to: Toni Nemec		Picture source: eBay.de		For these pictures special thanks to: arcadecollecting (eBay.com)		Picture source: eBay		For these pictures special thanks to: Bo Zimmerman			220-240V (PAL) version For these picture special thanks to: Thomas Kraft 100-120V (NTSC) version For this picture special thanks to: Bo Zimmerman			For these pictures special thanks to: Nagy Károly Source page: http://retropages.hu			For this pictures special thanks to: Dmitriy		Picture source: eBay.de For this picture thanks to: Michael Heuler				Picture source: eBay.com		For these pictures special thanks to: Detlef Böhler		Picture source: eBay.it			For these pictures special thanks to: Alexander Theodossiadis		Source: Mr.BomberMillzy (Amibay). Better photos needed!	Source: eBay.co.uk Better photos needed!	These photos by Guru	These images copyright by Richard Lagendijk Source page: http://www.richardlagendijk.nl		Source: Big Book Of Amiga Hardware		Source: ebay.de		For these pictures special thanks to: Bo Zimmerman		(C128 brochure UK) This scan thanks to Richard Lagendijk It seems this is the pre-production or "development system" version or prototype version of the later marketed final Commodore 1902 monitor. I know it is 1902 because it was written on the C128 brochure (above). It has the same chassis as the final Commodore 1902 but with different front enclosure. It seems it has appeared only in media (brochures, adverts, books and expos): "The Official Book for the Commodore 128" scan thanks to 1000 BiT Commodore PC (Blondie) - 1985 Australian TV Commercial (YouTube video) uloaded by mubd1234's Aussie Media Archive For this scan special thanks to: Bo Zimmerman Note that although this 1902 model was shown on UK brochure, Australian ad and German expo, but none of final 1902 models have PAL versions, and was never sold on PAL regions.		This scan thanks to Benj Edwards Most likely this is the pre-production or "development system" version or prototype version of the later marketed final Amiga 1080 monitor. It has the same chassis as the Commodore 1902 pre-production at the left column (so it has the same chassis as the final Amiga 1080 but with different front enclosure). It seems it has appeared only in media (brochures and adverts): This advert scan thanks to Ralph Torchia collected by The Commodore Billboard Searching for "1080" I have not found brochure or any image with this version of the monitor. Might the 1080 model number used only on the final/marketed version only. Some of you might think this simply the same as the 1902 pre-production version. This can be true only if these monitors are not works at all and was used only for visual demonstration on pictures, but the top image "We See Farther" (Electronic Arts) seems to show a working monitor (on the contrary with all the others), and the Commodore 1902 is not compatible with the analog RGB signal so cannot be used with Amiga RGB video out (the analog RGB successor of the 1902 was the 2002 monitor but it has arrived the next year, in 1986). It would only have been possible if the Amiga 1000's composite video output was used. Early adverts used different images with likely non real badges with "Amiga HR" text: For this scan special thanks to: Byte Cellar For this scan special thanks to: keving For this scan special thanks to: Classic Computer Magazine Archive So I have used the "Amiga HR" as model name in this column header. Note that the "Amiga Development System" looks different than Amiga 1000 has shown above pictures: For this great article and YouTube video special thanks to Amiga Love
display type	Analog RGB monitor		Analog/digital RGB and Luma/Chroma video monitor		Analog/digital RGB and SCART video monitor		Analog/digital RGB and SCART video monitor (SCART is stereo)		Analog/digital RGB and SCART video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog/digital RGB monitor		Analog/digital RGB and Luma/Chroma video monitor		Analog/digital RGB and Luma/Chroma video monitor		Analog/digital RGB and Luma/Chroma video monitor		Stereo analog/digital RGB and Luma/Chroma video monitor		Stereo analog/digital RGB and Luma/Chroma video monitor		Stereo analog/digital RGB and Luma/Chroma video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog/digital RGB and Luma/Chroma video monitor		Stereo analog/digital RGB and Luma/Chroma video monitor		Stereo analog/digital RGB and Luma/Chroma video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog RGB and Luma/Chroma video monitor		Stereo analog RGB monitor		High resolution monochrome composite monitor		High resolution monochrome composite monitor		MDA/Hercules monochrome monitor		VGA greyscale monitor		MDA/Hercules monochrome monitor		VGA greyscale monitor		VGA greyscale monitor		VGA monitor		VGA monitor 13.4"		VGA monitor		VGA monitor		VGA monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Luma/Chroma video monitor		Analog RGB and SCART composite monitor			MDA/Hercules monochrome monitor		Digital RGB and Luma/Chroma video monitor		Digital RGB and Luma/Chroma video monitor		Digital RGB and Luma/Chroma video monitor		VGA monitor		VGA monitor		VGA monitor		VGA monitor		VGA monitor		VGA monitor		VGA monitor		VGA monitor		VGA monitor		VGA monitor		Stereo bisync (BiScan) monitor		Stereo bisync (BiScan) monitor		VGA monitor		VGA monitor		Multisync (MultiScan) monitor		Multisync (MultiScan) monitor		Analog/digital RGB and Luma/Chroma video monitor			Analog/digital RGB and Luma/Chroma video monitor			MDA/Hercules monochrome monitor			MDA/Hercules monochrome monitor		High resolution greyscale analog Amiga monitor				Luma/Chroma video monitor		MDA/Hercules monochrome monitor		High resolution monochrome composite monitor			MDA/Hercules monochrome monitor		Multisync (MultiScan) monitor (15-37 or 38kHz)	Multisync (MultiScan) monitor (15-38kHz)	Luma/Chroma video monitor 5"	Multisync (MultiScan) 14" monitor (15-40kHz)		Multisync (MultiScan) 15" monitor (15-38kHz)		Multisync (MultiScan) 17" monitor (15-64kHz)		High resolution ECL monochrome bitmap monitor
made in	Japan		Japan		Taiwan		Taiwan		Taiwan		Korea		Taiwan		Taiwan		Korea		Taiwan		Korea		Korea		Korea		Korea		Korea		Taiwan		Taiwan		Taiwan		Taiwan		Malaysia		Malaysia		Korea		Korea		Korea		Singapore		Singapore		Korea		Taiwan		Korea		Korea		Taiwan		Korea		Korea		Korea		Korea		Korea		Japan		Japan		Korea		Japan		Korea		Korea		Korea		Korea		Korea		Korea		Korea			Taiwan		Singapore		Japan		Taiwan		Taiwan		Taiwan		Taiwan		Korea		Taiwan		Korea		Korea		Korea		Korea		Korea		Korea		Korea		Portugal		Finland		Taiwan		Taiwan		Japan			Taiwan			Taiwan			Korea		Taiwan				Korea		Taiwan		Taiwan			Taiwan		Japan	Japan	Japan	Rear label says England. Probably assembled there but actually made in Malaysia/China/Korea/Taiwan		Rear label says England. Probably assembled there but actually made in Malaysia/China/Korea/Taiwan		Rear label says England. Probably assembled there but actually made in Malaysia/China/Korea/Taiwan		?
manufacturer	Victor Company of Japan (JVC)		Toshiba		Philips		Philips		Philips		Daewoo		Philips		Philips		Daewoo		Philips		Daewoo		Daewoo		Daewoo		Daewoo		Daewoo		Philips		Philips		Philips		Philips		Likom 1		Likom 1		Daewoo		Daewoo		Daewoo		Thomson		Thomson		Hyundai		ADI		Hyundai		Hyundai		Philips		Samtron (Samsung)		Korea Data System Co., Ltd.		Samtron (Samsung)		Samtron (Samsung)		Samtron (Samsung)		Victor Company of Japan (JVC)		Victor Company of Japan (JVC)		GoldStar		Nagano JRC		GoldStar		GoldStar		GoldStar		Daewoo		Daewoo		Daewoo		Samsung?			N.A.P. = North American Philips		ESE: European Standard Electronics = Thomson		Fujitsu		Philips		Philips		Philips		LITE-ON		Samsung		LITE-ON		Samsung		Samsung		Samsung		Samsung		Samsung		Daewoo		Daewoo		Nokia		Nokia		AOC (Top Victory Electronics)		LITE-ON		Fujitsu			Philips			Philips			Samsung		ADI				GoldStar		ADI		Philips			Multitech Industrial Corp.		Iiyama (re-badged by Aydin Controls UK)	Iiyama (re-badged by Aydin Controls)	Matsushita	Microvitec		Microvitec		Microvitec		?
voltage versions	120V		120V		220-240V		220-240V		220-240V		220-240V		220-240V		100-120V 50-60Hz	220-240V	120V	220-240V	220-240V		120V	220-240V	120V	220-240V	120V	220-240V	120V	220-240V	220-240V		100-120V 50-60Hz	220-240V	120V	220-240V	220-240V		220-240V		220-240V		220-240V		220-240V		220-240V		220-240V		240V (with 2-pin AS/NZS 3112 Plug) & 12V DC Input		240V (with 2-pin AS/NZS 3112 Plug) & 12V DC Input		120V	220-240V	120V	220-240V	220-240V		220-240V		220-240V		100-240V 50-60Hz		90-240V 50-60Hz		100-240V 50-60Hz?		100-240V 50-60Hz		100-120V 60Hz		120V	220/240V	120V	220/240V	120V		220-240V		120V		120V		120V		120V	220-240V	120V	220-240V	120V	220-240V	220-240V			120V		220-240V		120V		100-120V 50-60Hz		120V	220-240V	220-240V		110-240V 50-60Hz		220-240V		110-240V 50-60Hz		220-240V		220-240V		220-240V		100-240V 50-60Hz		100-240V 50-60Hz		120V	220-240V	120V	220-240V	220-230V		220-230V		120V	200-240V	100-120V 50-60Hz	220-240V	120V			100-120V 50-60Hz	220-240V		220-240V			220-240V		120V	220-240V			120V		220-240V		220-240V			220-240V		110-120V/220-240V	110-120V/220-240V (voltage selection on rear via switch)	SX64 has either 120V/240V but actual tube is powered by lower voltage (12VDC) direct from the internal SX-64 switching power supply	240V (rear label) Official specs give: 90-265V 50-60Hz		240V (rear label) Official specs give: 90-265V 50-60Hz		240V (rear label) Official specs give: 90-265V 50-60Hz		220-240V ?
supported video input	analog RGB       └composite sync		analog RGB     └composite sync     digital RGBi (POS.)     low sync digital RGBi (NEG.)     NTSC separate     NTSC composite		analog RGB   └composite sync   digital RGBi   PAL separate (with 3rd party adapters via SCART connector)   PAL composite		analog RGB   └composite sync   digital RGBi   PAL separate (with 3rd party adapters via SCART connector)   PAL composite		analog RGB   └composite sync   digital RGBi   PAL separate (with 3rd party adapters via SCART connector)   PAL composite		analog RGB       └composite sync       PAL separate       PAL composite		analog RGB       ├composite sync       ├horizontal sync       └vertical sync       digital RGBi		analog RGB  ├horizontal sync  └vertical sync  digital RGBi  NTSC separate  NTSC composite	analog RGB  └composite sync  digital RGBi  PAL separate  PAL composite	analog RGB  └composite sync  digital RGBi  NTSC separate  NTSC composite	analog RGB  └composite sync  digital RGBi  PAL separate  PAL composite	analog RGB           ├horizontal sync           └vertical sync           digital RGBi           PAL separate           PAL composite		analog RGB  └composite sync  digital RGBi  NTSC separate  NTSC composite	analog RGB  └composite sync  digital RGBi  PAL separate  PAL composite	analog RGB  └composite sync  digital RGBi  NTSC separate  NTSC composite	analog RGB  └composite sync  digital RGBi  PAL separate  PAL composite	analog RGB  └composite sync  digital RGBi  NTSC separate  NTSC composite	analog RGB  └composite sync  digital RGBi  PAL separate  PAL composite	analog RGB  └composite sync  NTSC separate  NTSC composite	analog RGB  └composite sync  PAL separate  PAL composite	analog RGB       └composite sync       PAL separate       PAL composite		analog RGB    ├horizontal sync    └vertical sync    digital RGBi    NTSC separate    NTSC composite	analog RGB    ├horizontal sync    └vertical sync    digital RGBi    PAL separate    PAL composite	analog RGB    ├composite sync    ├horizontal sync    └vertical sync    digital RGBi    NTSC separate    NTSC composite	analog RGB    ├composite sync    ├horizontal sync    └vertical sync    digital RGBi    PAL separate    PAL composite	analog RGB       ├composite sync       ├horizontal sync       └vertical sync       digital RGBi       PAL separate       PAL composite		analog RGB       ├composite sync       ├horizontal sync       └vertical sync       PAL separate       PAL composite		analog RGB       └composite sync       PAL separate       PAL composite		analog RGB       └composite sync       PAL separate       PAL composite		analog RGB       └composite sync       PAL separate       PAL composite		analog RGB       └composite sync       PAL separate       PAL composite		analog RGB       └composite sync		Composite		Composite		MDA/Hercules		VGA		MDA/Hercules		VGA		VGA		VGA		VGA		VGA		VGA		VGA		NTSC separate  NTSC composite	PAL separate  PAL composite	NTSC separate  NTSC composite	PAL separate  PAL composite	NTSC separate       NTSC composite		PAL separate       PAL composite		NTSC separate       NTSC composite		NTSC separate       NTSC composite		NTSC separate       NTSC composite		NTSC separate  NTSC composite	PAL separate  PAL composite	NTSC separate  NTSC composite	PAL separate  PAL composite	NTSC separate  NTSC composite	PAL separate  PAL composite	analog RGB   └composite sync   PAL composite (with 3rd party adapters via SCART connector)			MDA/Hercules		digital RGBi        PAL separate        PAL composite With modification adding SCART connector to rear it can also do Analog RGB		digital RGBi (POS.)     low sync digital RGBi (NEG.)     NTSC separate     NTSC composite		digital RGBi          NTSC separate          NTSC composite		VGA		VGA		VGA		VGA		VGA		VGA		VGA		VGA		VGA		VGA		VGA        analog RGB        ├horizontal sync        └vertical sync		VGA        analog RGB        ├horizontal sync        └vertical sync		VGA		VGA		VGA        EGA        analog RGB        ├horizontal sync        └vertical sync        digital RGBi        MDA/Hercules		VGA        EGA        analog RGB        ├horizontal sync        └vertical sync        digital RGBi		analog RGB     └composite     digital RGBi (POS.)     low sync digital RGBi (NEG.)     NTSC separate     NTSC composite			analog RGB  ├horizontal sync  └vertical sync  digital RGBi  NTSC separate  NTSC composite	analog RGB  └composite sync  digital RGBi  PAL separate  PAL composite		MDA/Hercules			MDA/Hercules		analog RGB       ├horizontal sync       └vertical sync				NTSC separate       NTSC composite		MDA/Hercules		Composite			MDA/Hercules		VGA       EGA       analog RGB       ├composite sync       ├horizontal sync       └vertical sync       digital RGBi	VGA          EGA          analog RGB          ├composite sync          ├horizontal sync          └vertical sync          digital RGBi	SX-64 has no video input.   (Video input to the picture tube is   separate R, G, B, H-Sync & V-Sync.)	VGA        analog RGB        ├horizontal sync        └vertical sync		VGA        analog RGB        ├horizontal sync        └vertical sync		VGA        analog RGB        ├horizontal sync        └vertical sync		ECL
video connectors	female 9-pin D-sub (DE9F) connector		male 9-pin D-sub (DE9M) connector 2x RCA connector		female SCART connector female 8-pin DIN connector 1x RCA connector		female SCART connector female 8-pin DIN connector 1x RCA connector		female SCART connector female 8-pin DIN connector 1x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector		female 6-pin DIN connector female 8-pin DIN connector 2x RCA connector	female SCART connector female 8-pin DIN connector 2x RCA connector	male 9-pin D-sub (DE9M) connector 2x RCA connector		female 6-pin DIN connector female 8-pin DIN connector 2x RCA connector		male 9-pin D-sub (DE9M) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 6-pin DIN connector female 8-pin DIN connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector 2x RCA connector		female 9-pin D-sub (DE9F) connector		1x RCA connector		1x RCA connector		built in cable with male 9-pin D-sub (DE9M) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 9-pin D-sub (DE9M) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		2x RCA connector		2x RCA connector		2x RCA connector		2x RCA connector		2x RCA connector		2x RCA connector		2x RCA connector		2x RCA connector		2x RCA connector		2x RCA connector		female SCART connector			female 6-pin DIN connector		male 9-pin D-sub (DE9M) connector 2x RCA connector		male 9-pin D-sub (DE9M) connector 2x RCA connector		female 8-pin DIN connector female 6-pin DIN connector 1x RCA connector		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		female 9-pin D-sub (DE9F) connector		female 9-pin D-sub (DE9F) connector		built in cable with male 15-Pin D-Sub (HD-15) plug shipped with HD-15 to DB23F adapter (390682-01)		built in cable with male 15-Pin D-Sub (HD-15) plug shipped with HD-15 to DB23F adapter (390682-01)		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug		built in cable with male 15-Pin D-Sub (HD-15) plug shipped with HD-15 to DB23F adapter (390682-01) and HD-15 to DE9M adapter		built in cable with male 15-Pin D-Sub (HD-15) plug shipped with HD-15 to DB23F adapter (390682-01)		male 9-pin D-sub (DE9M) connector 2x RCA connector			female 6-pin DIN connector female 8-pin DIN connector 2x RCA connector	female SCART connector female 8-pin DIN connector 2x RCA connector		female 6-pin DIN connector			built in cable with male 9-pin D-sub (DE9M) plug		built in cable with female 23-pin D-sub (DB23F) plug				2x RCA connector		built in cable with male 9-pin D-sub (DE9M) plug		1x RCA connector			built in cable with male 9-pin D-sub (DE9M) plug		female 9-pin D-sub (DE9F) connector (RGB TTL) female 15-pin D-sub (DA15F) connector (RGB Analog)	female 9-pin D-sub (DE9F) connector (RGB TTL) female 15-pin D-sub (DA15F) connector (RGB Analog) BNC x5 (separate R, G, B, H-Sync, V-Sync) for both input and output with selectable BNC input voltage	SX-64 has no video input. Standard C64 female 8-pin DIN connector output from rear of SX64 to external monitor such as 1701 etc.	Built in cable with female 23-pin D-sub (DB23F) plug. Some may have shipped with male 15-Pin D-Sub (HD-15) plug and HD-15 to DB23F adapter (390682-01).		Built in cable with male 15-Pin D-Sub (HD-15) plug. Shipped with HD-15 to DB23F adapter (390682-01). Some may have female 23-pin D-sub (DB23F) plug.		Built in cable with male 15-Pin D-Sub (HD-15) plug. Shipped with HD-15 to DB23F adapter (390682-01).		female 8-pin DIN connector
audio connectors	1x RCA connector		1x RCA connector		1x RCA connector (the SCART has mono audio input)		1x RCA connector (the SCART has stereo audio input) 1x stereo TRS (3.5 mm jack) connector the cabinet has 2 speakers		1x RCA connector (the SCART has mono audio input)		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		1x RCA connector 1x mono TRS (3.5 mm jack) connector	1x RCA connector (the SCART has mono audio input) 1x mono TRS (3.5 mm jack) connector	1x RCA connector 1x mono TRS (3.5 mm jack) connector		1x RCA connector 1x mono TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		2x RCA connector 1x stereo TRS (3.5 mm jack) connector		1x RCA connector		1x RCA connector		none		none		none		none		none		none		none		none		none		none		1x RCA connector		1x RCA connector		1x RCA connector		1x RCA connector		1x RCA connector		1x RCA connector		1x RCA connector		1x RCA connector		1x RCA connector		1x RCA connector		(mono via SCART plug)			none		1x RCA connector		1x RCA connector		1x RCA connector (the 6-pin DIN connector has mono audio input)		none		none		none		none		none		none		none		none		none		none		2x RCA connector		2x RCA connector		none		none		none		none		1x RCA connector 1x mono TRS (3.5 mm jack) connector			1x RCA connector 1x mono TRS (3.5 mm jack) connector	1x RCA connector (the SCART has mono audio input) 1x mono TRS (3.5 mm jack) connector		none			none		none				1x RCA connector		none		1x RCA connector			none		none	none	internal speaker and mono output via standard C64 female 8 pin DIN	2x RCA connector		2x RCA connector		none		none
maximum resolution	"640x200" (should be able to 640x400 interlaced)		640x400 (interlaced)		"600 lines in centre"		"600 lines in centre"		"600 lines in centre"		640x512 (interlaced)		640x512 (interlaced)		"640 lines in centre"	"600 lines in centre"	"640 lines in centre"	"640 lines in centre"	"600 lines in centre"		"640x200" (640x400 interlaced)	640x512 (interlaced)	640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		"640 lines in centre"	"600 lines in centre"	640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		640x512 (interlaced)		80-column		80-column		720x350		640x480		720x350		640x480 ?		?		?		1024x768 (interlaced)		1024x768 ?		640x480		640x480		40-column		40-column		40-column		40-column		40-column		40-column		40-column		40-column		40-column		40-column		320x512 (interlaced)			720x350		80-column		80-column		640 lines in centre		640x480		640x480		[Wanted!]		640x480		1024x768 (interlaced)		[Wanted!]		1024x768		1024x768		1024x768		1024x768		800x600		800x600		1024x768?		1024x768?		800x600		1024x768 (interlaced)		"640x200" (should be able to 640x400 interlaced)			640 lines in centre ?			720x350			720x350		1024x800 (OCS: 1008x800)	1024x1024 (OCS: 1008x1024)			40-column		720x350		"850 lines in centre"			720x350		800x600 (non-interlaced) 1024x768 (interlaced)	likely 800x600 (non-interlaced) 1024x768 (interlaced)	40 column	800x600 (non-interlaced) 1024x768 (interlaced)		800x600 (non-interlaced) 1024x768 (interlaced)		1024x768 76Hz 1152x870 68Hz 1280x1024 60Hz		1024x800 72Hz
release date	1985		1985		1986 (main PCB mfg date 1986 week 16)		1986 (main PCB mfg date 1986 week 20)		1986 (main PCB mfg date 1986 week 26)		1992		1991		1987		1988		1988?		1988-Jun-14 (signature date of the user's guide)		1989?		1992-Jan		1992-Feb		1992-Feb		1988		1989-Oct-05 (signature date of the user's guide)		1991?		1992?		1992		1994 (after Commodore's bankruptcy)		1991?		1992-Jan?		1992-Feb		1985?		1985?		1988		1988		1989		1991?		1992?		1992		1993		?		1989 or 1990		1989		1983 (introduced on 1983 Winter Consumer Electronics Show, Las Vegas, January 6-9 source)	1983-Jun-30 (signature date of the user's guide)	1983		1984?		1985-Feb-28 (signature date of the user's guide)		1984		1984		1986		1986		1988		1992?		1992 (copyright year of the user's guide)			1985		somewhere between 1985-Sep-04 and 1985-Dec-01		1985		1986?		1988?		1991?		1992		1992?		1992?		1992?		1992?		1992?		1993?		1993?		1993		1993		1993		1993		1990		1991-Sep (1st printing date of the user's guide)		1986			1987			1985			1989		1988-Dec-7 (release date of the Workbench 1.3/2024)				1984		1987-Mar?		1985?			1987-Sep?		somewhere between 1989 and 1991	somewhere between 1989 and 1991	1984-Jan (release date of SX-64)	1995		1996		1996		(not released)
chassis design	?		Commodore #2		Philips CM8500		Philips CM8500		Philips CM8500		Commodore #4		Commodore #4		Philips CM8500		Commodore #2		Philips CM8500		Commodore #2		Commodore #4		Commodore #4		Commodore #4		Commodore #4		Philips CM8500		Commodore #4		Commodore #4		Commodore #4		Likom #1		Likom #1b		Commodore #4		Commodore #4		Commodore #4		Thomson #1		Thomson #1		Hyundai #1		ADI		Hyundai #2		Hyundai #3		Philips #4		Samtron #2		KDS		Samtron #2b		Samtron #2		Samtron #1		JVC TM-13U		JVC TM-13U		Commodore #1		Commodore #1b		Commodore #1		Commodore #1		Commodore #1		Daewoo		Commodore #3		Commodore #3		a television case?			Philips BM7500		Thomson #2		Commodore #2		Philips CM8500		Philips #4		Philips #4		LITE-ON		Samsung #2		LITE-ON		Samsung #2		Samsung #2		Samsung #2		Samsung #2		Samsung #2		Commodore #4		Commodore #4		Nokia		Nokia		AOC		LITE-ON		Commodore #2			Philips CM8500			Philips/Magnavox BM7622			Samsung #1		ADI				Commodore #1		ADI		Philips/Magnavox BM7622			Multitech Industrial Corp.		Likely IDEK/Iiyama MF-5015 or MF-5015A	IDEK/Iiyama MF-5021 (MULTIFLAT 21)	n/a	Microvitec Desk-Scan 1402		Microvitec Desk-Scan 1501		?		?
best matching for (by time and class)	Amiga 1000		Amiga 1000		Amiga 1000		Amiga 1000		Amiga 1000		Amiga 500 Plus; Amiga 600		late Amiga 2000; late Amiga 500		early Amiga 2000; early Amiga 500; late Commodore PCs in CGA mode		early Amiga 2000; early Amiga 500		Amiga 2000; Amiga 500; late Commodore PCs in CGA mode		Amiga 2000; Amiga 500; Amiga 2500		late Amiga 2000; late Amiga 500; Amiga 1500		Amiga 500 Plus; Amiga 600		Amiga 500 Plus; Amiga 600		Commodore CDTV		Amiga 2000; Amiga 500; Amiga 2500		late Amiga 2000; late Amiga 500; Amiga 1500		Commodore CDTV		Amiga 500 Plus; Amiga 600		Amiga 500 Plus; Amiga 600		Amiga 600		late Amiga 2000; late Amiga 500		Amiga 500 Plus; Amiga 600		Amiga 500 Plus; Amiga 600		Commodore 64; Commodore 128 (with 3rd party adapter)		Commodore 16; Commodore Plus/4		Commodore PC-I (PC 1); PC 5; PC60/40; PC60/80; Colt; PC10-III; PC20-III		Commodore PC40-III; PC50-II; DT 286; SL 286; SL 386SX		Commodore PC10-III; PC20-III; PC30-III (in MDA/Hercules mode)						late Commodore PCs with VGA		latest Commodore PCs with VGA		late Commodore PCs with VGA		late Commodore PCs with VGA		late Commodore PCs with VGA		Commodore 64 (with 5-pin video and rainbow badge); Commodore VIC-20 (rainbow lines badge); Commodore VC-20 (rainbow lines badge) for silver label Commodore 64 go here		Commodore 64 (with 8-pin video and rainbow badge)		Commodore 16; Commodore Plus/4		Commodore 16; Commodore 116; Commodore Plus/4		Commodore 16; Commodore Plus/4		Commodore 16; Commodore Plus/4		early Commodore 64C (C64C)		early Commodore 64C (C64C)		Commodore 64C (C64C); Commodore 64G (C64G)		late Commodore 64C (C64C)		Late Amiga 500, Amiga 500 Plus			Commodore PC10; PC20; PC30; PC10-II; PC20-II; PC 40/20; PC 40/40		Commodore 128; 128D; early Commodore PCs in CGA mode		Commodore 128 (the monitor has back legs to sit on a flat C128); early Commodore PCs in CGA mode		Commodore 128D; Commodore PCs in CGA mode		Commodore PC40-III; PC60-III; PC50-II; DT 286; SL 286; SL 386SX; DT 386; TW 386; Amiga 3000		late Commodore PCs with VGA		late Commodore PCs with VGA		late Commodore PCs with VGA		late Commodore PCs with VGA		late Commodore PCs with VGA		late Commodore PCs with VGA		late Commodore PCs with VGA		latest Commodore PCs with VGA		latest Commodore PCs with VGA		Amiga 1200		Amiga 1200		latest Commodore PCs with VGA		latest Commodore PCs with VGA		Amiga 3000; Commodore PC30-III; PC60-III		Amiga 4000; Amiga 1200		Commodore 128 (the monitor has back legs to sit on a flat C128); Amiga 1000			early Amiga 2000; early Amiga 500			Commodore PC10; PC20; PC30; PC10-II; PC20-II; PC 40/20; PC 40/40; PC-I (PC 1); PC 5			Commodore PC10-III; PC20-III; PC30-III (in MDA/Hercules mode)		Amiga 2000				Commodore 16; Commodore Plus/4; Commodore 264-series		Commodore PC 40/20; PC 40/40		Commodore 64; Commodore 128 (with 3rd party adapter)			Commodore PC 40/20; PC 40/40 PC10-III; PC20-III		Amiga 3000	Amiga 3000	Commodore SX-64	Amiga Technologies Amiga 1200 & 4000T		Amiga Technologies Amiga 1200 & 4000T		Amiga Technologies Amiga 1200 & 4000T		Commodore 900 WORKSTATION (prototype)
user's manual	Special thanks for this scans to M.A.Grundke (dead link) Copyright © by Commodore Electronics Limited		PDF		PDF								JPG & GIF in LHA		PDF	PNG in LHA					PDF (you can search within)	PNG						PDF	PDF			PNG		PDF	PDF				PDF								PDF (you can search within)							PDF also good for Hyundai HMM-1200			PDF also good for Hyundai HMM-1401																PDF (you can search within)	PDF	PDF (you can search within)				PDF (you can search within)		PDF (you can search within)		PDF (you can search within)				PDF (you can search within)											PDF		PDF		PDF (you can search within)																						PDF								PDF		PNG		PDF (you can search within)						PNG special thanks to Jonas G.! :)			Samsung SM-12SFA7 schematics		PDF				PNG				JPG							PDF (full)	PDF (you can search within) (English, French, German, Italian, Dutch, Norwegian) PDF (you can search within) (German)		[wanted !]		PDF
service manual, schematic diagram			PDF (with schematic) scanned by DLH (except the schematic) Schematic from Ray Carlsen's Home Page		TIF (schematic) scanned by Guru; PDF (photocopied full service manual but good quality)								see Commodore 1084S-P1 (PAL) (except Luma/Chroma part)		PDF (full); PNG (schematic) PDF (schematic) also good for Magnavox CM8505; CM8562; CM8705; CM8762; 8CM505; 8CM515; 8CM542; 8CM643	high resolution TIF (schematic) scanned by Guru smaller: GIF1 GIF2 (from http://www.devili.iki.fi)		PDF (full) also good for Deawoo CMC-146PRI			PDF (schematic, better scan) PNG (schematic) also good for Daewoo CMC-146NR			PDF (full service manual 240V). Also good for 1084S-D2 which is identical minus the RGBi circuit		PDF (full service manual 240V). Also good for 1084S-D2 which is identical minus the RGBi circuit		See 1084S-D1 Service Manual	See 1084S-D1 Service Manual		PDF (full) also good for Magnavox CM8505; CM8562; CM8705; CM8762; 8CM505; 8CM515; 8CM542; 8CM643	photocopied, PDF (T07-639) scanned by me; Philips CM8833 PDF (full) (T07-639) scanned by HansO; PDF (schematic) (T32-630) CM8833 is also good for 1084S-P (220-240V)		PDF (full) also good for Philips CM8833 II High quality Philips CM8833 II service manual (full)	PDF (full) also good for Philips CM8833 II High quality Philips CM8833 II service manual (full)																				PDF also good for ADI DM-3014						PDF (full service manual)												PNG (schematic); PDF (full)		PDF (full)		likely you can use CM-141 service manual and schematic				PDF (full) JPG (schematic) also good for Goldstar CMC 141		PDF (full) JPG (schematic) also good for Goldstar CMC 141		PDF (full) JPG (schematic) also good for Goldstar CMC 141		PDF (full)									PDF (full, low quality) PDF (full, high quality) also good for Magnavox BM7513; 7BM613; BM7523; 7BM623		Technical Manual PDF (full, low quality) Service Manual PDF (full, high quality)		JPG1 JPG2 (schematics) From Ray Carlsen's Home Page		PDF (most pages); JPG (schematic) The JPG from Ray Carlsen's Home Page		PDF (full, you can search within)								PDF scanned by me												PDF								GIF (schematic, partial) also good for AOC CM314 From Ray Carlsen's Home Page	PDF (schematic)	PDF (full, you can search within) PDF (full, character recognized with some badly recognized character)		PDF (service manual without schematic) GIF (schematic) from Ray Carlsen's Home Page PNG (schematic)						maybe you can use the Philips BM7513/BM7523 schematic side A side B			Samsung SM-12SFA7 schematics						JPG (schematic) also good for Goldstar CMC 141				maybe you can use the Philips BM75xx service manual							Service Manuals: PDF (120V, full) PDF (240V, full)
repair info	Picture tube(s): M34JAL70X				Picture tube(s): Chunghwa E2971B22-TC DT(Y) CPJ37OBVAPIU-TC Original Flyback: Philips E39144 AT2076 36731 (Philips part number: 3291000006) Replacement Flyback: HR Diemen HR 6489 1081 dark tube mono capacitor list		Picture tube(s): Chunghwa E2971B22-TC DT(Y) CPJ37OBVAPIU-TC Original Flyback: Philips E39144 AT2076 36731 (Philips part number: 3291000006) Replacement Flyback: HR Diemen HR 6489 1081 dark tube stereo capacitor list		Picture tube(s): Philips M34EAQ01X Philips M34EAQ10X not Philips M34EAQ1OX nor Philips M34EAQO1X Original Flyback: Philips E39144 AT2076 36731 (Philips part number: 3291000006) Replacement Flyback: HR Diemen HR 6489 likely you can use the "1081 dark tube mono capacitor list" with slightly differences		Tube/Flyback probably same as 1084S-D1		Tube/Flyback probably same as 1084S-P1		Picture Tube: Philips M34EAQ00X Original Flyback: Philips E39144 AT2076 36731 (Philips part number: 3291000006) Replacement Flyback: HR Diemen HR 6489 1084 capacitor list		Flybacks: HR46045; DCF1580; KFS60559; BSC23-21550; MSH1FCT31		Tube probably same as 1084 Original flyback: Philips E39144 TYPE AT2079 30102 Replacement Flyback: HR Diemen HR 7506 replacing the flyback (video) 1084-P capacitor list		Flybacks: HR46045; DCF1580; KFS60559; BSC23-21550; MSH1FCT31		Picture Tube(s): Orion M34JRW30X04; Samsung 37SGA54X-TC16; Toshiba E2940B22-TC10ETHT Flybacks: HR46045; DCF1580; KFS60559; BSC23-21550; MSH1FCT31 1084S-D1&D2 capacitor list 1084S-D2 to D1 conversion								Picture Tube(s): Philips M34EAQ01X; Philips M34EAQ10X Original flyback: Philips E39144 TYPE AT2079 30102 Replacement Flyback: HR Diemen HR 7506 1084S-P capacitor list		Picture Tube(s): Philips M34EAQ01X; Philips M34EAQ10X Original Flyback: Philips E39144 AT2079 37591 Replacement Flyback: HR Diemen HR 7533 1084S-P1 capacitor list				Tube/Flyback probably same as 1084S-P1		Flyback: HR7495				Tube/Flyback probably same as 1084S-D1				Picture Tube(s): Orion A34JLL43X52 Flyback: 199A-E21 1085S-D3 capacitor list		Picture tube(s): 12NBYLAN		Picture tube(s): 12NBYLAN ?																						Picture Tube: HITACHI 370FVB22 1701 capacitor list		Picture Tubes: HITACHI 370FVB22 Toshiba 370KRB22				Picture Tube: Mitsubishi 370JWB22 P								1802 tall 120V capacitor list (generated by referencing the Commodore 1802 NTSC schematic, NOT verified!)	Picture Tube(s): Orion 370EGB22 Original flyback: MSH1FBL33 Replacement Flyback: HR7458; DCF2078 1802 tall 220-240V capacitor list	Picture tube(s): Orion A34JLL92X29 Flyback: DCF-2078									Flyback: HR7041		Picture tube(s): Hitachi M34JND12X Toshiba E2940B22-GT Flyback: muRATA MHF064-31 (MSH1FBU90)																																		Picture Tube: Panasonic M34KBV80X11 Flyback: HR 46259		Picture tube(s): Toshiba E2940B22-GT Hitachi M34JND12X Flyback: muRATA MHF064-31 (MSH1FBU90)			Picture Tube: Toshiba E2971XLB Original Flyback: Philips E39144 AT2076 36731 (Philips part number: 3291000006) Replacement Flyback: HR Diemen HR 6489 2080 PAL capacitor list 2080 PAL board pictures																							Picture Tube: Matsushita 150BMB22 SX-64 monitor capacitor list	Flyback: ZTFJ14335F M1438S capacitor list
others	dot pitch: 0.31 mm mfg's model name: CM20311-005 This monitor is ultra rare, great collector item!		dot pitch: 0.42 mm alternative name: 1080 A (in the service manual) The mode switch on the back side switches between: "DIGITAL POS." (high sync digital RGBi) "DIGITAL NEG." (low sync digital RGBi) "ANALOG" For the NTSC Commodore 128 family you should use "DIGILAT POS" position of this switch. FCC ID: AGI9XA-1080		dot pitch: 0.39 mm alternative names: Amiga 1081 Commodore 1081 "TYPE 1081" continental Europe "230V~50Hz 75W" "TYPE 1081 UK" United Kingdom "230V~50Hz" [if exist] "TYPE 1081 AU" Australia "240V±10% AC 50Hz" mfg's model names: KH543/00E (1081) KH543/05E (1081 UK) [if exist] KH543/75E (1081 AU) Main board: 3138 103 31851 or 3138 103 30853 Neck board: 3138 103 31871 Power board: 3138 103 31861 Amp board: not used This was the first analog RGB (Amiga) monitor from Commodore in the PAL regions of the world. The yoke manufacturer the same as at 2080. (also good for Highscreen KP548)		dot pitch: 0.39 mm alternative names: Amiga 1081 Commodore 1081 1081S "TYPE 1081" continental Europe "230V~50Hz 75W" "TYPE 1081 UK" United Kingdom "230V~50Hz" [if exist] "TYPE 1081 AU" Australia "240V±10% AC 50Hz" [if exist] mfg's model names: KH543/00E (1081) KH543/05E (1081 UK) [if exist] KH543/75E (1081 AU) [if exist] Main board: 3138 103 30852 Neck board: 3138 103 30871 Power board: 3138 103 30861 Amp board: 3138 103 30830 This was the first stereo monitor (via SCART plug) from Commodore The yoke manufacturer the same as at 2080. (also good for Highscreen KP548)		dot pitch: 0.42 mm alternative names: Amiga 1081 Commodore 1081 "TYPE 1081" continental Europe "230V~50Hz 75W" "TYPE 1081 UK" United Kingdom "230V~50Hz" "TYPE 1081 AU" Australia "240V±10% AC 50Hz" mfg's model names: KH533/00E (1081) KH533/05E (1081 UK) KH533/75E (1081 AU) Main board: 3138 103 30853 Neck board: 3138 103 31871 Power board: 3138 103 31861 Amp board: not used (also good for Highscreen KP548)		dot pitch: 0.42 mm It seems it is a Commodore 1084S-D2 with a "1083S-D1" sticker on it's backplate label. Question is why???		dot pitch: 0.42 mm There is a common false belief saying that the 1083S-P1 is a SECAM monitor. This is false because 1083S-P1 have no composite or separate video input. 1083S-P1 was sold in France only to avoid the SECAM ↔ PAL color problems like connecting a SECAM Commodore 64 to a PAL monitor (SECAM Commodore 64 display greyscale picture on a PAL monitor). SECAM Commodore 64 was made for SECAM TVs. Malgré ce que certains pensent, le 1083S-P1 n'est pas un moniteur SECAM. Il ne dispose pas de sortie Composite ou S-Video. Ce moniteur n'a été vendu qu'en France pour éviter les problèmes de couleurs SECAM ↔ PAL comme avec le branchement d'un C64 SECAM sur un moniteur PAL.		dot pitch: 0.42 mm alternative name: 1084P (in the service manual) "MODEL NO. 1084" North America    "115V AC 50/60Hz 75W" "TYPE 1084 VDE" continental Europe    "230V~50Hz 75W"    VDE=Verband der Elektrotechnik "TYPE 1084 BSI" United Kingdom    "230V~50Hz 75W"    BSI=British Standards Institution "TYPE 1084 AU" in Australia    "240V±10% AC 50Hz" mfg's model names (220-240V versions only): KH533/20E (1084 VDE) KH533/25E (1084 BSI) KH533/95E (1084 AU) FCC ID (120V version only): BOU9Q21902A (the same as the FCC ID of the 1902A) pinout for 120V version pinout for 220-240V versions (same as the 1081 pinout)		Appears to be the Daewoo version of the Commodore 2002 (with same specifications) FCC ID (120V version only): BR97NF1084-D		"TYPE 1084-P VDE" continental Europe    "220V~50Hz 75W"    VDE=Verband der Elektrotechnik		dot pitch: 0.42 mm FCC ID (120V version only): BR97NF1084S-D		dot pitch: 0.42 mm FCC ID (120V version only): BR91084S-D1		dot pitch: 0.42 mm FCC ID (120V version only): BR91084S-D1		FCC ID (120V version only): BR91084S-D1 (the same as the FCC ID of the 1084S-D1)				dot pitch: 0.42 mm "MODEL NO. 1084S-P" North America    "115V AC 50/60Hz 75W" "TYPE 1084S-P VDE" continental Europe    "230V~50Hz 75W"    VDE=Verband der Elektrotechnik "TYPE 1084S-P BSI" United Kingdom    "230V~50Hz 75W"    BSI=British Standards Institution "TYPE 1084S-P AU" in Australia    "240V±10% AC 50Hz" mfg's model names (220-240V versions only): KH533/30E (1084S-P VDE) KH533/35E (1084S-P BSI) KH533/96E (1084S-P AU) FCC ID (120V version only): BOU9Q21902A (the same as the FCC ID of the 1902A)		dot pitch: 0.42 mm				same specification as 1084S-P1 but with the rear TTL/Analog RGB switch removed		dot pitch: 0.42 mm Some say on the net that the 1084ST has made by Philips. Philips have made all of its monitors in Taiwan that times but this monitor has made in Malaysia. I think it was made by Likom that company established in Malaysia in 1992 http://www.likom.com.my/ProsServ/DP/PS_DP_Capable.asp#1 (on archive.org) Although the box says "1084 ST CGA" this monitor does NOT support CGA/RGBi mode! The Commodore 1084ST from 1992 uses Philips M34EAQ01X picture tube, but exist 1084ST with Hitachi tube.								dot pitch: 0.52 mm		alternative name: Commodore 231201 monitor (on it's box) This model was sold only in Australia and New Zealand. Rear-Panel Connectors & Controls: Mains Power Lead (AUS/NZ 2-pin Plug. 240V AC, 50Hz, 26W) Horizontal Position Adjust Vertical Position Adjust 12V DC Input RCA Audio Input RCA Video Input Because the power consumption is 26 Watt you should use an adapter at least 2.2A for the 12V DC input. Picture source: eBay.au John Klumpp's review: "The input sockets takes a pair of RCA connectors, for mono audio and mono (composite) video. I was initially using this to view 80-column C128 displays. I did use the item with various Amiga models since it was my smallest/lightest monitor & I could double-up for displays when performing video grabs (DigiView & VidiAmiga 24 RT Pro) with the D23 port. As to the resolution it could display Amiga PAL 640x512 and went right to the corner-curves of the CRT. The unit was a handy workhorse and I tried to display NTSC VHS 50Hz at one time . . . actually viewing a shrunken image (that rolled) on it back when I had no NTSC-capable displays. Australia's analog TV is PAL 60Hz. I can testify that broadcast television looks quite strange in orange-screen monochrome!" The Thomson-made Commodore 1201 is based on Thomson's own monitor Thomson VM3101G (meant for use with the Thomson MO5 computer) picture source: ebay.com (Does it exist in 120V also?) picture source: Obsolete Tears - Musée Virtuel de l'Histoire de la micro et du jeu vidéo						FCC ID (120V version only): BR88YWDM-3014								dot pitch: 0.28 mm mfg's model name: SC-428VS FCC ID: CSYSC-431VS This model has sold only in Canada.		dot pitch: 0.28 mm FCC ID: EVO CORNET This model has sold only in Canada. "Note that the Commodore nameplate on the front does not fit neatly into a recess as on the Samtron model; instead it is pasted on top and is not flush with the monitor surface. I assume that it covers the manufacturer's name. On the back it is more obvious that the Commodore nameplate is poorly applied to the identification logo."  - Ernie Chorny According to my research the original model has sold by Orchestra MultiSystems, Inc. and manufactured by KDS (Korea Data System Co., Ltd.) Orchestra webpage for Cornet-14" (on archive.org): http://www.orchestra.com/cornet.htm		dot pitch: 0.28 mm ? mfg's model name: SC-428VX ? FCC ID: CSYSC-428VX ? This model has sold only in Canada.		dot pitch: 0.31 mm mfg's model name: SC-431VII (I think the "VII" as "V" two) FCC ID: CSYSC-431VA This model has sold only in Canada.		dot pitch: 0.31 mm mfg's model name: SC-431V FCC ID: CSY7Y6SC-431V This model has sold only in Canada.		dot pitch: 0.64 mm FCC ID (120V version only): ASI9OY008 Although this model have separate video (on the back of the monitor) Commodore has shipped it with a 5-pin DIN video cable.		mfg's model names: (early models in North America have no mfg's model name) CM20311-B03 (late North American) CM20311-B04 (latest North American) CM20649-001 (UK, Australia and New Zealand) CM20716-002 (continental Europe) FCC ID (120V version only): ASI9OY008 (the same as the FCC ID of the 1701) Shipped it with a 8-pin DIN (separate luma and chroma) video cable.		This model has monitor filter		This model has monitor filter dot pitch: 0.67 mm		This model has monitor filter FCC ID: BEJ9QK1802 The Commodore backplate label and the Gold Star sticker are black		This model has monitor filter FCC ID: BEJ9QK1802 The Commodore backplate label is brown but the Gold Star sticker is black		This model has monitor filter FCC ID: BEJ9QK1802 The Commodore backplate label is white but the Gold Star sticker is black		alternative name: Commodore 1802C FCC ID (120V version only): BR97NF1802		FCC ID (120V version only): BR97NF1802 (the same as the FCC ID of the 1802 tall)		FCC ID (120V version only): BR97NF1802 (the same as the FCC ID of the 1802 tall)		alternative name: Commodore Amiga 1803 I think this is a modified small TV from a Korean manufacturer. Extremely rare collector item!			alternative name: PC 1901 (in the service manual) mfg's model names: 75BM13/72E 75BM13/74E FCC ID: BOU 9Q2M003		alternative name: Commodore Video Monitor 1901 This monitor can be modified to add SCART connector and get full color analog RGB for use with Amiga		The mode switch on the back side switches between: "DIGITAL POS." (high sync digital RGBi) "DIGITAL NEG." (low sync digital RGBi) For the NTSC Commodore 128 family you should use "DIGILAT POS" position of this switch. FCC ID: ASJ9PO1902 not ASJ9P01902 :)		FCC ID: BOU9Q21902A												This model is a re-badged Samsung SyncMaster 3		This model is a re-badged Samsung SyncMaster 3		This model is a re-badged Samsung SyncMaster 3		This model is a re-badged Samsung SyncMaster 3		This model is a re-badged Samsung SyncMaster 3		dot pitch: 0.39 mm FCC ID (120V version only): BR9581940		dot pitch: 0.28 mm FCC ID (120V version only): BR9581940 (the same as the FCC ID of the 1940)						dot pitch: 0.31 mm Model names: 1950-A; 1950-B FCC ID (120V version only): ARSCM3140A The 200-240V version is a bit rare. more info about Commodore 1950 monitor		dot pitch: 0.28 mm FCC ID (120V version only): H4ICM14001		Updated version of the 1902: the analog RGB capability has added. The mode switch on the back side switches between: "DIGITAL POS." (high sync digital RGBi) "DIGITAL NEG." (low sync digital RGBi) "ANALOG" For the NTSC Commodore 128 family you should use "DIGILAT POS" position of this switch. FCC ID: ASJ9PO2002 not ASJ9P02002 :)			Essentially a 1081 with a high persistence phosphor tube to reduce flicker in hi-res modes. This monitor is therefore not suitable with fast moving images such as games or animation which will appear blurry. MODEL NO. 2080" North America    "115V AC 50/60Hz 75W" "TYPE 2080 VDE" continental Europe    "230V~50Hz 75W"    VDE=Verband der Elektrotechnik mfg's model names (220-240V versions only): KH553/20E (2080 VDE) FCC ID: BOU9Q21902A (the same as the FCC ID of the 1902A) The yoke and neck board are specific to the special high persistence tube of the monitor. pinout for 120V version pinout for 220-240V versions (same as the 1081 pinout)			alternative names: 76 BM13 (in the users manual) Commodore BM13 mfg's model names: 76BM13/00E (continental Europe) 76BM13/05E (United Kingdom) 76BM13/75E (Australia)					alternative name: Hedley Hi-Res (because of developer Hedley Davis) This monitor is rare, great collector item!				This model has monitor filter FCC ID: BEJ9QKCM141 This is the original design that the 1801/1802 is based on. The CM-141 was darker to match the color scheme of the 264-series.				alternative name: Commodore DM 602 mfg's model name: DM602/00E					dot pitch: 0.31 mm It seems this model was sold only in UK. The Ranger lines re-badged by AYDIN CONTROLS (UK) for Commodore UK (Aydin has also "Ranger" line: "Ranger 5015LP"; "Ranger 5021"; "Ranger 5017" and later models too). These monitors manufactured by Iiyama Electric Co., Ltd. Japan. IDEK/Iiyama own models in the "MULTIFLAT" line: "MF-5015"; "MF-5015A"; "MF-5021" and "MF-5017". These monitors are FST (Flat Square Tube). AYDIN marketed it's model (5015LP) as longer phosphor persistence, but original Iiyama (IDEK) models known as short phosphor persistence. Amiga World Magazine (Volume 9, Number 6, June 1993): "In addition to the 5017SP, IDEK makes the MF-5017LP, which uses a long-persistence phosphor. Long-persistence monitors substantially reduce interlace flicker, which may make the 5017LP the best choice to use with the 800x600 interlaced Super72 display mode. IDEK also makes the short-persistence monitor 15-inch (MF-5015) and 21-inch (MF-5021A) models." source	dot pitch: 0.31 mm It seems this model was sold only in UK. This is a high-end studio monitor. The German BBoAH says this is a rebadged Aydin Ranger 5021 BBoAH link First I have seek old AYDIN and iiyama back labels, and iiyama is full different than Commodore RANGER 21 but AYDIN is really similar: So AYDIN pack its AYDIN RANGER 5021 model for Commodore. But AYDIN is a UK company but this monitor has made in Japan, and AYDIN RANGER 5021 looks full the same as IDEK Iiyama MF-5021 (BBoAH (David Ward) has written the same model number). So Commodore do business with AYDIN who sells restickered IDEK/Iiyama MF-5021 monitors. This iiyama picture I have get from PC Magazine 1992-Jan-14. Also I think Commodore (and AYDIN) RANGER 21 monitors are have sold only in UK and probably only to people buying Amiga 3000. Now clear that the manufacturer is IDEK/Iiyama and the "case design" is IDEK/Iiyama MF-5021 (21inch FST) but we would say some word about Commodore UK have no direct contact to IDEK/Iiyama but they has made deal with AYDIN UK. In the year I'm not sure because the PC Magazine 1992-Jan-14 that show MF-5021 infos shows 4 newer 21" models too. So the 1992 must be the last year for this model. Iiyama history writes: 1989 Introduced 21" FST (https://iiyama.com/gb_en/company/) So the year must be between 1989 and 1992. An Amiga World user guide from 1991 show AYDIN RANGER 5021 (http://encanta.avalonsoftware.org/idgaw/guia91/hard_equipos.php). But problem that iiyama says the resolution is 1024x768 but this guide says 1280x1280. BBoAH mention this monitor as 21inch FST as iiyama in the history 21" FST too. FST is an iiyama term that means "Flat Square Tube".	The SX-64 is a very high quality computer. Components and modules for the SX-64 were manufactured by several Japanese companies and then assembled by Commodore.	Manufactured by Microvitec for Amiga Technologies. 0.28mm dot pitch The same models: Microvitec 1438 CEI A1962 Acorn AKF50		Manufactured by Microvitec for Amiga Technologies. 0.28mm dot pitch		Manufactured by Microvitec for Amiga Technologies. 0.28mm dot pitch		The "HR monitor" come from the sticker above the 8-pin plug of the back side of the Commodore 900 workstation computer: For this picture special thanks to: Bo Zimmerman The 8-pin DIN connector pinout on the computer: For this picture special thanks to: Bo Zimmerman
additional photos or additional info	A 240V modded 1070 in Australia:						For this pictures special thanks to: www.nerdone.it more pictures see there.				Scart cable tutorial (FR) Source page: https://adzone.free.fr																		Great pictures on www.nightfallcrew.com																																																				Great pictures on www.nightfallcrew.com																																																							For this pictures special thanks to: Steve J. Gray The following pics by me (Gona)			Pictures about the 220-240V EU (VDE) version by Thomas Kraft: Pictures about the 100-120V version by Steve J. Gray: Pictures about the 100-120V version by Bo Zimmerman:						For this pictures special thanks to: Dmitriy		The power LED of the Commodore A2024 is in the Commodore logo. Red one: Picture source: WorthPoint (eBay) Green one: Picture source: TechJump YouTube channel				For this pictures special thanks to: Richard Belden							For this pictures special thanks to: Alexander Theodossiadis and for the last one to: Petr Váradi (www.kompjutry.cz)				These photos by Guru							On Bo Zimmerman's CBM-PICS page

(different color models, different badge types and the three 1081 models are merged)

Babel:
RGB linear = Analog RGB => used for Amiga (and MSX; Atari ST; Apple IIGS)
RGB TTL = Digital RGB = RGBI (RGB with Intensity) => used for CGA and C128 (in C128 "80-column" mode)
Commodore video = Separate Video = S-Video = SVHS (but not Super VHS) = Y/C = Separate Luma and Chroma = Separate Luminance and Chrominance
Separate LCA = Separate Luma/Chroma/Audio
CVBS (Color-Video-Blank-Sync) = FBAS (Farbe-Bild-Austastung-Synchron) = Composite video
Euroconnector = EuroAV = EuroSCART = SCART = Péritel = Péritélévision = Peritelevisons-Verbindung = EIA Multiport
Phono jack connector = RCA connector = Cinch connector

Most wanted:
service manual of the Commodore 1084ST
pictures about any other Commodore monitor models
pictures about Commodore monitor models with not listed voltage version
user's manual of the Commodore 1201
any other user manual or service manual or schematic not listed on this site

Special thanks to:
Richard Lagendijk
Steve Gray
Paul Andrews
Bo Zimmerman Commodore Gallery; CBM-PICS page
tizeta2
John Klumpp http://home.people.net.au/~vortexau/ (dead link)
M.A.Grundke
Nagy Károly
Tomi Tilli
http://www.retrocomputer.tux.hu
Obligement - L'Amiga au maximum > Les moniteurs Commodore – French translation of my site with vertical table
Ernie Chorny
Guru
Karl Asseily

Sources:
Commodore manuals and schematics
DLH's Commodore Archive (lot of Service manuals)
Bo Zimmerman's Commodore gallery
Ray Carlsen's Home Page (Carlsen Electronics): Schematic diagrams for Commodore monitors, computers, RAM expansion units, EPROM adaptors, etc.
John Klumpp: Australian Commodore Brochure from about 1988 ("Commodore Brochure from the late 1980s" right side scan)
Gregory Donner's Workbench Nostalgia
Niila T Rautanen Computer Pages: Commodore
German Wikipedia: Commodore PC-10 bis PC-60
www.commodorebillboard.de
MSXPró - Home Page (15KHz monitors)
www.atarimagazines.com/compute



Changes:
2011-Feb-06: I have upload the 1081 manual and 1084S-D manuals; fill the dot pitch info for 1081 (from this manual); modified a little bit the 1084S-D resolution info; modified a little bit the 1070 resolution info; update the 1201 section very well.
2011-Mar-09: I have found a Commodore 1950 monitor on Australian eBay, I asked and I have got backlabel picture. I have never seen before 200-240V version of 1950. I have modified the 1950 sections, the 1950 page and the Commodore monitor compatibility matrix for 220-240V page.
2011-Mar-15: Made and upload the Commodore 1902A manual in PDF.
2011-Mar-19: I have bought an European 1701 manual. It is write "Hersteller" (manufacturer): "Victor Company of Japan, Ltd.". I remembered "NEC" not "JVC". Sorry for my mistake, I have replaced the tree "NEC" to "JVC". The European 1701 is later than North-American I also update this; release date of Commodore 1084-D changed from 1987 to 1988 according it's manual.
2011-Mar-20: Correcting differencies between the two Commodore monitor pages (the 12V DC input of the 1201 has missed from one of them); I have got a Hyundai HMM-1401 MDA/Hercules monitor manual. This model the same as the Commodore 1404 (except the power switch on the front on HMM-1401 but on the 1402 on back side). So 1402, 1404 and 1405 are made by Hyundai.
2011-May-10: I have all of the tree MFG codes for 1081 voltage versions so I have upload this data. Special thanks to sanpomaru!
2011-May-18: I have all of the tree MFG codes for 1084 (the original "boxy") voltage versions so I have upload this data. Special thanks to markline1100!
2011-May-18: I have got mfg number of the 1084 BSI. Special thanks to airey36!
2011-May-20: Research that result the 76BM13/05E is a UK version. This was not clear because the only I have found it in a continental Europe collection with replaced power cord (so the built in power cord with UK plug has replaced to continental EU plug). Special thanks for this research to Nagy Károly!
2011-Jun-03: I have got the "Commodore 1084S-P AU" MFG code: KH533/96E Special thanks to blackdugall!
2011-Jun-09: An other type Commodore Amiga 1081 has added. This has different mfg code likely because Philips has not used own picture tube. The first piece of this type I have found on Italian eBay and the seller has asseverated that this is stereo (via SCART plug) but this is fals, Guru has also this type revision 1081 and it is mono (but have picture tube made by the Taiwanese Chunghwa Picture Tubes, LTD).
2011-Dec-27: Error correction on the "Commodore monitors by time" page: The "audio connector" field of the Commodore 1802 tall was missed and the raw was slipped from this field (all field show the entry of the next monitor) to the last item on this page (1084ST) which had no field.
2011-Dec-27: Commodore DM-14 (ADI DM-14) pictures from Germany. The case design the same as the 1403 and the A2024 case (so these are made by ADI also). For the Commodore DM-14 pictures special thanks to Detlef Böhler!
2012-May-06: Commodore 1960 and 1935 are made by LITE-ON according to Commodore 1960 SERVICE MANUAL; Service manual/schematic raw added.
2012-May-10: Uploading service manuals and schematics; Freshly scanned "76 BM13 & 76 BM23" users manual, special thanks to Jonas G.!
2012-May-20: Philips (N.A.P.; Magnavox) DIN pinouts (also good for models that sold under Highscreen name); manual uploads
2012-Oct-02: I have merged the "220/240V" and the "240V" columns of the 1702 because the 1702 models sold in UK (special thanks this picture to jonnixx) and Australia (special thanks this picture to Tom Szabo) also have the 220/240 voltage switch on the back side of the monitor. I have also merged the 1801 and 1802 "tall" 220 and 240 versions.
2012-Oct-02: FCC ID for 1701/1702 and five MFG codes for 1702 and one for the 1070.
2012-Oct-07: 1084ST picture tube information (Philips M34EAQ01X), special thanks to http://www.retrocomputer.tux.hu!
2012-Oct-07: I have added the "case design" row. Special thanks to Paul Andrews for the idea.
2012-Oct-07: I have found 1930-III pictures on http://www.mingos-commodorepage.com
2012-Oct-13: My Likom theory about 1084ST.
2012-Oct-13: Diagram about manufacturers added.
2012-Nov-16: SECAM false belief about 1083S-P1 added. Special thanks for the compacted French version to David Brunet at http://obligement.free.fr/
2012-Nov-16: Updated A2024 resolution informations according to Toni Wilen (WinUAE developer, Grand Master): http://eab.abime.net/showthread.php?t=62030#2
2013-Apr-13: I have upload all of the 1084S-P1 pictures that Tomi Tilli has sent to me. Thank you much!
2013-Apr-13: I have got big, clear and sharp photos about 1085S-D2 from alex76gr. I have upload all of them. Special thanks to alex76gr!
2014-Feb-23: Commodore 1703 pictures added from ebay.com, and separated page for 1703 (click on picture); Likom link changed to an archived version (archive.org); Philips BM7513/BM7523 schematic scanned by me.
2014-Feb-26: I got more info about 1703 (made by GoldStar, made in Korea).
2014-Jun-13: Pictures about European Commodore 2080 model. This is the last model under Commodore name that has EuroSCART connector. It is really rare. Special thanks to Thomas Kraft for the great pictures! :)
2014-Jun-13: Error correction: The original Commodore 1084 monitor also has a headphone 3.5 mm jack (mono) at the left side.
2014-Jun-14: Update: Commodore 1960 supports CGA (digital RGBi) and EGA signals too, according to it's service manual.
2015-Apr-04: New model: Commodore 1803! Special Thanks to Henrik Brinch Christiansen who inform me about the auction and also Special Thanks to Fabien Patricia (the seller) who has made pictures about manual pages after I have ask them.
2015-Apr-11: New models: Commodore 1428; 1428X; 1432D; 1432V! Special Thanks to Ernie Chorny who make the pictures for me and send informations too about this rare models.
2015-May-23: New color version: Commodore 1802 dark brown. Special Thanks to Mike Holmes who make and send the pictures to me.
2015-Sep-24: FCC ID numbers now are links to https://fccid.io/ (FCC ID Application Database)
2015-Sep-24: New model: Commodore 1428 (Cornet-14") ! Special Thanks to Ernie Chorny who make the pictures for me and send informations too about this really rare model.
2016-Sep-23: New model: Commodore 1935LR
2016-Sep-23: New model: Commodore 1936LR
2017-Mar-27: Repair info raw has added
2017-Mar-27: Commodore Amiga 1081 schematic has added. Special thanks to Guru who scan it and send to me! The Guru's ROM Dump News
2017-Mar-28: Commodore Amiga 1084 high resolution schematic has uploaded. Special thanks to Guru who scan it and send to me! The Guru's ROM Dump News
2017-Mar-29: Commodore 1084S-D2 manual has added. Special thanks to Guru who scan it and send to me! The Guru's ROM Dump News
2017-Mar-30: Commodore Amiga 1081 section clean up. Special thanks to Guru for detailed informations! The Guru's ROM Dump News
2017-Mar-30: Amiga 1080 schematic has added. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Mar-30: Amiga 1080 manual has added. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Apr-01: New Commodore Amiga 1081 (with darker tube) picture. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Apr-01: Commodore 1084S-D 120V schematic in PDF (a better scan quality) has uploaded. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Apr-01: Commodore 1950 220-240V schematic in PDF has uploaded. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Apr-03: Commodore 1940 service manual and user's guide in PDF has uploaded, and dot pitch informations according to these has added. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Apr-05: Commodore 1950 user's guide in PDF has uploaded. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Apr-06: Commodore A2024 user's guide in PDF has uploaded. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2017-Apr-06: Commodore 1084S-P monitor capacitor list compiled by Guru has uploaded. Special thanks to Guru for this important work! The Guru's ROM Dump News
2017-Apr-09: Commodore 1084S-D1&D2 monitor capacitor list compiled by Guru has uploaded. Special thanks to Guru for this important work! The Guru's ROM Dump News
2017-Apr-09: Commodore 1902; 1084 120V; 1084S-P1 220-240V and 1084ST user's guide in PDF (scanned by me) has uploaded.
2017-Apr-15: Some pictures replaced, some picture dead links changed to my backup images.
2017-Apr-15: The mysterious Commodore 1944S has added from German eBay. May be post Commodore. If you have bought this monitor please contact me.
2017-May-20: Inside pictures about Commodore 2080 has added. Special thanks to: Bo Zimmerman
2017-May-21: The Commodore 1944S is a VGA only monitor. For this information special thanks to Sascha!
2017-Apr-22: After many days of work, Guru has completed new site design with added 'Highslide' picture zooming.
2017-Apr-22: Guru added Escom/Amiga Technologies monitors for Commodore Amiga computers.
2017-May-23: Amiga M1764 manual (scanned by me) has uploaded.
2017-Sep-01: I found 'Commodore Ranger 15' pics on AmiBaY and Guru found 'Commodore Ranger 21' pics on eBay. Guru added pics for Commodore Ranger 15 & Commodore Ranger 21 monitors that we found. This is an important update because I want more than one source as David Ward (because he has sold him 21inch monitor years before I wrote him in Dec 2009). If you own these monitors please send us some better photos
2017-Sep-01: Guru added pics of inside of Commodore CM-141. For these photos special thanks to Richard Belden.
2017-Sep-01: Guru added some larger and better pics of Commodore 1702, and Commodore 1080 and Commodore 1084S-D1 monitors and boxes!
2017-Sep-01: Guru added Commodore SX64 with built in 5" monitor
2017-Sep-01: Guru added Commodore 1081 monitor capacitor list
2017-Sep-01: Guru added Commodore SX-64 monitor capacitor list
2017-Sep-01: Guru added Commodore 1084S-D2 to 1084S-D1 monitor conversion info. Add these parts to make your D2 into a D1! Source: Amibay
2017-Sep-01: Guru added Commodore 1901 Color Video Monitor Technical Manual. Better scan is wanted
2017-Sep-02: Guru added Commodore 1901 Color Video Monitor Service Manual (High Quality) with high quality schematics on two single sheets like the original manual!
2017-Sep-02: Guru added Commodore 1901 Monochrome Monitor Service Manual (High Quality).
2017-Oct-06: Philips CM8833 service manual - a photocopied one but good quality - (scanned by me and converted to PDF by Guru) has added.
2017-Oct-06: Commodore 1935 service manual (scanned by me and converted to PDF by Guru) has added.
2017-Oct-23: Amiga RGB (DB-23) to Iiyama (and AYDIN/Commodore Ranger) DA-15 pinout (discovered by me) has added.
2017-Oct-31: Guru added Commodore 1081 Monitor Service Manual. Source: a1k.org
2017-Oct-31: Guru added Commodore 1084S-D1 Monitor Service Manual. Source: a1k.org
2017-Oct-31: Guru added Commodore 1407 Monitor Service Manual. Source: a1k.org
2017-Oct-31: Guru added Commodore 2002 Monitor Service Manual. Source: a1k.org
2017-Nov-01: Commodore CM-141 service manual from Bo Zimmerman's schematics gallery has added.
2017-Nov-02: Commodore 1084S-P NTSC Service Manual in High Quality (scanned by me and big schematics pages are merged and all of them converted to PDF by Guru) has added.
2017-Nov-12: Inside pics of my Commodore 2002 monitor has added.
2018-Feb-22: Commodore 1802 (tall) 120V manual; 1930 120V service manual and an other 1960 service manual has added. Special thanks to Guru who send it to me! The Guru's ROM Dump News
2018-Oct-12: Guru added additional pics of Commodore 1901 Video Monitor.
2018-Oct-30: Capacitor lists compiled by Guru has uploaded.
2018-Nov-02: Error correction: I have mixed up 1802 (tall) NTSC versus PAL picture tube and flyback informations. Corrected.
2018-Dec-01: Capacitor lists compiled by Karl Asseily has uploaded.
2019-Apr-11: Some picture tube and flyback informations are filled/updated by Guru.
2019-Apr-11: M1438S capacitor list compiled by Karl Asseily has uploaded.
2020-May-14: For the Commodore 1901 video monitor release I have written "1986-Feb-13 (signature date of the user's guide)" but I got a Commodore price list for 1985-Dec with this model. Special thanks for this information to Anders Carlsson.
2020-Jun-01: 1801 and 1084S-D2 black tube infos and links to www.nightfallcrew.com 1801 and 1084S-D2 articles. Special thanks to Xad Nightfall.
2020-Jul-06: 1085S user manual has added. Special thanks to leZone: http://adzone.free.fr .
2021-Jan-30: M1438S English manual has added. Special thanks to leZone: http://adzone.free.fr .
2021-Feb-12: Commodore MM-14 has added. Special thanks to for these great pictures to Alexander Theodossiadis.
2021-Jun-04: Sticky table headers for better scroll has added. Special tanks to Peter Godwin who has sent it to me.
2021-Jun-14: Additional Commodore 1802 brown pictures has added. Special thanks to for these great pictures to liqmatrix.
2021-Jun-14: Additional Commodore 1201 beige pictures has added. Special thanks to for these great pictures to Zeromega.
2021-Aug-24: Commodore Amiga 1081 stereo column has added. Special thanks to for these great pictures to Luca ＠ www.nerdone.it.
2021-Aug-24: Commodore Amiga 1081 stereo electrolytic capacitors list has added. Special thanks to Luca for this list www.nerdone.it.
2022-Apr-10: Commodore 1085S-D3 pictures (inside too), tube and flyback info has added. Special thanks to Hugo Barata.
2022-Apr-10: Correct Flyback transformer for Commodore 1084-P VDE monitor has added. Special thanks to Doktor64 (YouTube).
2022-Apr-12: Doktor 64 Commodore 1084-P monitor repair (replacing the flyback) video has added.
2022-Apr-23: Commodore 1802D with gray badge tube and flyback info has added. Special thanks to Guru.
2022-May-30: Commodore 1802D additional pictures has uploaded. Special thanks to Guru.
2022-May-30: Commodore 1070 240V modded pictures has uploaded. Special thanks to Dorian Benedetti.
2022-May-30: Now I write Analog RGB sync type (for Atari ST users).
2022-Nov-11: Mistype correction, I have accidentally deleted the "digital RGBi" line of the Commodore 1084S-P1 PAL (from supported video input).
2022-Dec-31: Great pictures about Commodore 1936A has uploaded, special thanks to Dorian Benedetti!
2023-Jan-24: A2024 power LED in the Commodore logo pictutres; monitor of the Commodore 900 workstation; "Amiga HR" and Commodore 1902 pre-production versions has added.
2023-Mar-04: Commodore 2080 PAL capacitor list and board pictures, special thanks to Lars Ove Fossheim!
2024-Mar-17: Error correction: Commodore 2002 back mode switch erratic description now corrected. Added to 1080 too and switch description for 1902. Special Thanks to Mike Holmes who notice it.
2024-Aug-07: Pictures about Commodore 99STRIM has uploaded, special thanks to Dmitriy!
2024-Aug-11: Picture about Commodore 1944 has uploaded, special thanks to Toni Nemec!





Visitors per capita percent up to 2022.Dec.22:

Malta	0,0229%
Finland	0,02197%
Hungary	0,01778%
Sweden	0,01627%
Denmark	0,01488%
Norway	0,01434%
Australia	0,00957%
Greece	0,00941%
Netherlands	0,00789%
Italy	0,00748%
Germany	0,00698%
Poland	0,00667%
New Zealand	0,00619%
Canada	0,00586%
Croatia	0,00581%
Czech	0,0058%
Luxembourg	0,00557%
Austria	0,00518%
Switzerland	0,0049%
Belgium	0,00478%
UK	0,00419%
Ireland	0,00404%
Slovenia	0,00341%
Portugal	0,0031%
USA	0,00309%
Serbia	0,00299%
Cyprus	0,00257%
Slovakia	0,0024%
Spain	0,00239%
